Product Details:
Payment & Shipping Terms:
|
| Features: | No UV | Power: | 300W |
|---|---|---|---|
| VF: | 42V | IF: | 7.5A |
| Chip: | CREE LED | Color Temperature: | 6000-8000K |
| Highlight: | high power led array,led lighting engine |
||
300watt 42V LED Light Engine White 6000K - 8000K CREE Flip-chip LED
Features:
1. Excellent Transiting Heat from LED Chip Operating under 7.5A
2. High Luminous Output
3. No UV
4. Light emitting area is small, power per unit area of up to 5W/mm ²
5. Three color and four color melange effect is superior to similar products on the light
6. Quick on/off; Anti-poisonous or toxic, comply with RoHS
Specifications:
| Code | Color | Vf (V) | If (A) | CCT(K) | φv(lm) | Power | LES(mm) |
| TX-5266W300FC120-NUVENG-A02 | White | 40-44 | 7.5 | 6500-9500 | 22000-23000 | 300 | 9 x 9 Φ11 |
Applications:
Entertainment lighting, Projection lights, Moving-Heads, SPOT, GOBO
Architectural lighting
Medical illumination
Event / Effect Lighting
Stage lighting Projection
