Flip-chip White LED Diode 60 W High Lumen LED Emitter with High Light Density

China Flip-chip White LED Diode 60 W High Lumen LED Emitter with High Light Density supplier

Large Image :  Flip-chip White LED Diode 60 W High Lumen LED Emitter with High Light Density

Product Details:

Place of Origin: CN
Brand Name: TYANSHINE
Certification: ISO9001:2008 SGS RoHS
Model Number: TX-1818W60FC120-CUHCNG-A01

Payment & Shipping Terms:

Minimum Order Quantity: 10pcs
Packaging Details: In Tray
Supply Ability: 5000pcs/Month
Contact Now
Detailed Product Description
Chip: Cree Flip-chip Power: 60Watt
VF: 28-32V IF: 2.2A
Lumen: 4400-4800lm CCT: 6000K-8000K
LES: 9x9mm
High Light:

white led chip

,

white led array

Flip-chip White LED Diode 60 W High Lumen LED Emitter with High Light Density





Brief Introduction of LED Modules:



  1. High Brightness with CREE Flip-chip LEDs, Quality assured LED Components for Entertainment Lighting products;
  2. Eutectic bonding to make sure the fast conductivity of heat, it's aim to the lumen maintenance;
  3. Small Light Emiting surface(LES) to enhance the light density;
  4. Using copper MCPCB to carry the LED chips, the LEDs can be installed directly to the heat sinks.



Specifications:



Absolute Maximum Ratings at Ta=85℃



Item Code





TX-1818W60FC120-CUHCNG-A01



Parameter Symbol Value Unit
LED Junction Temperature Tj 150
Power Dissipation PD 60 W
Continuous Forward Current IF 2.2 A
ElectrostaticDischarge Threshoid ESD 2000 V

Characteristics at If= 2.2A (Ta=85°C):

Parameter Symbol Values Units
Min. Typical Max.
Luminous Flux φV 4400 4800 - lm
Viewing Angle at 50﹪IV 1/2 - 120 - degree
Forward Voltage Vf 28 30 32 V
Correlated Colour Temperature CCT 6500 7500 8500 K
Thermal Resistance Junction to Case J-C - 0.2 - K/W



Package Dimensions:



             Flip-chip White LED Diode 60 W High Lumen LED Emitter with High Light Density



Applications:



Entertainment Lighting - LED Moveing-Heads Beam & Spot washing

Architectural illumination

Medical illumination

Flip-chip White LED Diode 60 W High Lumen LED Emitter with High Light Density
