Smart Lighting 500mA RGBW LED 70W COB LED LES12mm 36V LED COB RGBW

: Large Image : Smart Lighting 500mA RGBW LED 70W COB LED LES12mm 36V LED COB RGBW

Product Details:

Place of Origin:	CN
Brand Name:	TYANSHINE
Certification:	ISO9001:2008 ROHS SGS
Model Number:	TX-1818RGBW30FC120-CUHCNG-01

Payment & Shipping Terms:

Minimum Order Quantity:	10
Packaging Details:	In tray
Payment Terms:	Western Union, T/T, L/C

Contact Now

Detailed Product Description

Color:	RGBW	Current:	500mA
Voltage:	36V	Power:	70W
LES:	Φ12mm	CRI:	90+
Dimension:	19 X 19 Mm
Highlight:	rgb power led , led light module

Smart Lighting 400mA RGBW LED 70W COB LED LES12mm 36V LED COB RGBW

Key Features:

■ Excellent color-mixing, no color deviation, even color spot;

■ Cross-distribution of different colors, no polarized light;

■ High light quality, anti-glare

■ Fast thermal conductivity substrate, lower resistance

■ Compatible COB PKG size, easy to adapt accessories

Specifications:

Code

Color

(V)

(mA)

CRI

CCT

Power

LES

(mm)

TX-1919RGBW70C12V12-02H90

RGBW

36V

500

90+

6000K

70W

Φ12mm

Characteristics at If=450mA (Ta=25°C)

Parameter	Symbol	Emitting Color	Values
			Min.	Typ.	Max.
Luminous Flux	φ_v	R	550lm	700lm	-
		G	920lm	1160lm	-
		B	230lm	290lm	-
		W	1020lm	1200lm	-
Dominant Wavelength	λd	R	620nm	625nm	630nm
		G	522nm	527nm	532nm
		B	450nm	455nm	460nm
Colour Temperature	CCT	W	5500K	-	6000K
Forward Voltage	V_f	R	31V	33V	36V
		G	33V	36V	39V
		B	33V	36V	39V
		W	33V	36V	39V

Smart Lighting 500mA RGBW LED 70W COB LED LES12mm 36V LED COB RGBW

Applications:

Entertainment lighting,

Architectural lighting

Smart lighting

Event lighting

Commercial Lighting
